VMOR205SS
DMOR205SS
PRODUCT DESCRIPTION
GENERAL INFORMATION
OPERATION
TROUBLESHOOTING GUIDE AND
TEST PROCEDURE
TOUCH CONTROL PANEL
COMPONENT REPLACEMENT
AND ADJUSTMENT PROCEDURE
WIRING DIAGRAM
PARTS LIST
SERVICE MANUAL
VIKING RANGE CORPORATION
MICROWAVE OVENS
FOREWORD
This Manual has been prepared to provide Viking Service Personnel with
Operation and Service Information for the VIKING MICROWAVE OVENS,
VMOR205SS and DMOR205SS.
It is recommended that service personnel carefully study the entire text
of this manual and the base model's manual so that they will be qualified
to render satisfactory customer service.
Check the interlock switches and the door seal carefully. Special
attention should be given to avoid electrical shock and microwave
radiation hazard.
WARNING
Never operate the oven until the following points are ensured:
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is no other visible damage with the oven.
Servicing and repair work must be carried out only by trained service
personnel.
DANGER
Certain initial parts are intentionally not grounded and present
a risk of electrical shock only during servicing. Service person-
nel - Do not contact the following parts while the appliance is
energized;
High Voltage Capacitor, Power Transformer, Magnetron, High
Voltage Rectifier Assembly, High Voltage Harness;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked “*” on parts list are used at voltages more than
250V.
Removal of the outer wrap gives access to voltage above 250V.
VIKING RANGE CORPORATION
111 Front St., Greenwood, MS 38930
Tel: (888) 845-4641
VMOR205SS
DMOR205SS
