Viking DMOR205SS - Parts List

49
VMOR205SS
DMOR205SS
PARTS LIST
REF. NO. PART NO. DESCRIPTION Q'TY
ELECTRIC PARTS
1- 1 FH-DZB017MRY0 High voltage rectifier assembly 1
1- 2 RC-QZA234WRE0 High voltage capacitor 1
1- 3 QFS-TA013WRE0 Temperature fuse 150
°C 1
1- 4 RHET-A174WRE0 Convection heater 1
1- 5 RMOTDA264WRZZ Turntable motor 1
1- 6 RMOTDA270WRZZ Stirrer motor 1
1- 7 RTHM-0044MRE0 Thermal cut-out N.O. 60
°C 1
1- 8 RTRN-B070MRE0 Power transformer 1
1- 9 RV-MZA331WRZZ Magnetron 1
1-10 QFSHDB003MRE0 Fuse holder 1
1-11 QSW-MA085WRE0 Secondary interlock, third door sensing and damper switches 3
1-12 FFS-BA018/KIT Monitor and sec. interlock switch with fuse assembly 1
1-13 FACCDB011MRE0 Power supply cord 1
1-14 QSOCLB006MRE0 Hood lamp socket 2
1-15 FH-HZA053WRE0 Thermistor 1
1-16 QSOCLB006MRE0 Oven lamp socket 1
1-17 FMOTEA362WRK0 Hood fan motor 1
1-18 RMOTEA343WRE0 Convection motor 1
1-19 RMOTEB032MRE0 Fan motor 1
1-20 RLMPTA086WRZZ Hood lamp and oven lamp 2
1-21 FDTCTA217WRKZ AH sensor 1
1-22 RMOTDA268WRZZ Damper motor 1
1-23 RR-WZA031WRE0 Noise resistor 1
1-24 FPWBFB014MRK0 Noise filter 1
1-25 RLMPTB003WRE0 Hood lamp 1
CABINET PARTS
2- 1 PFIL-B005MRE0 Grease filter 2
2- 2 FDIF-B017MRK0 Hood exhaust louver (VMOR205SS) 1
2- 2 FDIF-B018MRK0 Hood exhaust louver (DMOR205SS) 1
2- 3 GDAI-B052MRP0A Base plate right 1
2- 4 GDAI-B039MRP0A Base plate left 1
2- 5 FCABUB081MRP0 Outer case cabinet 1
2- 6 TMAPCB103MRR0 Schematic diagram 1
2- 7 FANGKB009MRY0 Hood lamp glass assembly 1
2- 8 PCOVPB030MRT0D Base cover 1
2- 9 FDECAB079MRK0 Left Sash assy (VMOR205SS) 1
2- 9 FDECAB080MRK0 Left Sash assy (DMOR205SS) 1
2-10 LSTY-B010MRP0 Rear stay 1
CONTROL PANEL PARTS
3- 1 DPWBFB108MRU0 Control unit 1
3- 2 FPNLCB508MRK0 Control panel sub. assembly (VMOR205SS) 1
3- 2 FPNLCB509MRK0 Control panel sub. assembly (DMOR205SS) 1
3- 3 MSPRCA045WRE0 Open button spring 1
3- 4 FDECAB081MRK0 Open button assy (VMOR205SS) 1
3- 4 FDECAB082MRK0 Open button assy (DMOR205SS) 1
3- 5 XEPSD30P10XS0 Screw; 3mm x 10mm 8
