Viking E-30 - Programming Examples

To Program the E-30 Phone...
...to store 123456 as the security code
...to store a Touch Tone 9, a four second pause and then a pulse
dialed 333-4444 in the first speed dial position
...to store 555-1234 in the second speed dial position
Step 2 - Enter Digits:
1 2 3 4 5 6 # 1 9
9
,7 ,6 3 3 3 4 4 4 4 # 0 0
5 5 5 1 2 3 4 # 0 1
Step 1 -
See Section A
Enter Programming
Enter Programming
Enter Programming
G. Programming Examples
7
O
O
p
p
e
e
r
r
a
a
t
t
i
i
o
o
n
n
When the “Call” button is pressed, the E-30 phone goes off-hook, and dials a pre-programmed telephone number. The front
panel LED will light any time the phone is off hook. In the event that the line is busy or there is a ring-no answer, the unit
can be programmed to call additional phone numbers. The phone then cycles through up to 5 pre-programmed speed dial
numbers until the call is answered. The E-30 will hang up on CPC, silence, busy signal, return to dial tone, time out or Touch
Tone command (
,#). If programmed to auto-answer, the E-30 will also answer any incoming call. The E-30 color video
camera operates completely independently of the E-30 phone board. With power supplied to the camera, it will continuously
output a video signal.
A
A
p
p
p
p
l
l
i
i
c
c
a
a
t
t
i
i
o
o
n
n
s
s
C-2000A Advanced Door/Gate and Entry Phone Controller
Entry Phone 1
E-50-SS shown,
not included
(Example: Front Door)
VIKING
©
MODEL C-2000A
VIKING
ELECTRONICS
HUDSON, WI 54016
ADVANCED DOOR/GATE AND
ENTRY PHONE CONTROLLER
1 2 3 4 5
67
8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
PWR 13.8 VAC
EARTH GND ENTRY PHONE 1 DOOR STRIKE 1 ENTRY PHONE 2 DOOR STRIKE 2 ENTRY PHONE 3 DOOR STRIKE 3 ENTRY PHONE 4 DOOR STRIKE 4 DOORBELL SWITCH / AUX. INPUT AUX. CONTACT OUTPUT PHONE LINE INPUT LINE OUT TO PHONES
C.O. / Phone
Line Input
To Standard
Analog Touch
Tone House
Phone(s)
or
Entry Phone 4, K-1705-3 in VE-6x7 shown,
not included (Example: Gate)
Entry Phone 2, E-50-SS
shown, not included
(Example: Back Door)
To Entry Phone 4
(Power typically not
required for gate controllers)
Doorstrike/
Magnetic Lock
5A@30VDC/
250VAC
maximum
A contact closure output is available for each
entry phone. An auxiliary output is also available.
* Earth
Ground
(optional)
Optional Doorbell Switch
(not included, see Programming
section L on page 5)
Optional Postal Lock
(not included)
See DIP Switch Programming
Programming section C (page 4)
13.8V AC
Adapter
(included)
120V AC
Entry Phone 3, E-30 in VE-5x5 shown, not included
(Example: Garage)
To Gate
Controller
Tip (Audio)
Ring
Tip (Audio)
Ring
Video Out
Example:
2-4 Channel Video
RF Modulator
Example:
Amplified
RF Splitter
Video Out
Multi Room
Video Out
02
Antenna,
CATV, etc.
1 2 3 4
The C-2000A allows up to 4 entry phones to call into your existing residential or business phones or phone system. Tenants
may answer the call, converse with the visitor and activate a contact closure to control electronic gates or door strikes. The
C-2000A provides “Caller ID,” “Call Waiting ID” and “Call Waiting” tone when the phone line is in use. Tenants may gain
entry at each gate by entering a Touch Tone keyless entry code. Tenants may call out to each entry phone for monitoring
purposes. An auxiliary input is also available for connecting a common garage door opener/receiver and auxiliary keyless
entry keypads.
