Viking FDSB5423 - Custom Door Panel Dimensions

19
Headline
19
Custom Door Panel Dimensions
28-5/16”
(71.9 cm)
75-1/2”
(191.8 cm)
3/4”
(1.9 cm)
18-11/16”
(47.5 cm)
3/4”
(1.9 cm)
22-13/16”
(57.9 cm)
75-1/2”
(191.8 cm)
3/4”
(1.9 cm)
3/4”
(1.9 cm)
18-3/16”
(46.2 cm)
42” Side-By-Side
48” Side-By-Side
Note: Panel overlays must be dry, solid,
straight one piece panels. The use of multiple
panel pieces to achieve the dimensions is not
recommended.
Maximum Panel WT
42" 48"
Freezer 30lbs (13.6 kg) 30lbs (13.6 kg)
Refrigerator 38lbs (17.2 kg) 48lbs (21.8 kg)
