5
Tipping Radius - Door Swing
42" Door Swing
48" Door Swing
42" Side Tip
90°
90°
110°
110°
120°
120°
42”
(106.7 cm)
16-1/3”
(41.5 cm)
17 1/16”
(43.3 cm)
20-11/16”
(52.5 cm)
19-3/16”
(48.7 cm)
(38.4 cm)
15-1/8”
9-1/16”
(23.0 cm)
6-5/16”
(16.0 cm)
7-7/8”
(20.0 cm)
11-3/8”
(28.9 cm)
(55.1 cm)
21-11/16”
90°
90°
110°
110°
120°
120°
48”
(121.9 cm)
17”
(43.2 cm)
17 3/4”
(45.1 cm)
24-1/16”
(61.1 cm)
26”
(66.0 cm)
27-3/8”
(69.5 cm)
(40.0 cm)
15-3/4”
9-5/8”
(23.7 cm)
6-1/2”
(16.5 cm)
14-1/8”
(35.9 cm)
9-3/4”
(24.8 cm)
125 1/8" (317.8 cm)
82 3/4"
(210.1 cm)
92 15/16"
(236.1 cm)
42"
(106.7 cm)
