Viking Professional Custom VDSC5304B Installation Instructions

SCREW B
SCREW B
SCREW B
SCREW B
2" (5.1 cm) For 27" W
and 30" W lower oven
4" (10.2 cm) For 36" W
lower oven
Illustration 5
Illustration 6
Viking Range Corporation
111 Front Street • Greenwood, Mississippi (MS) 38930 USA • (662) 455-1200
Specifications subject to change without notice.
For more product information, call 1-888-VIKING1 (845-4641), or visit our web site at http://www.vikingrange.com
F20196C (PS0506VR)
TINSEB453MRR0
FRAME INSTALLATION
Position the FRAME ASSEMBLY to be square with the
oven. Carefully place the FRAME ASSEMBLY on the oven.
Check that it is level and then secure with two SCREWS
B. See Illustration 5. Secure the bottom portion of the
FRAME ASSEMBLY with the two remaining SCREWS B.
OVER OVEN INSTALLATION
See Illustration 6.
