BASIC SPECIFICATIONS AND DIMENSIONS
VCBB363-DUAL INSTALLATION
DDEESSCCRRIIPPTTIIOONN BBRRTTGGKK7722SSSS PPBBRRTTGGKK7722SSSS
Overall Width 72” (182.9 cm)
Overall Height from Bottom Min. 82 3/4” (210.2 cm)
Max. 84 1/16” (213.5 cm)
Overall Depth from Rear To rear edge of side trim 22 3/16” (56.4 cm)
To front of top grille 24 11/16” (62.7 cm)
To end of handle bracket 27 1/4” (69.2 cm)
Cutout Width 71 1/2” (181.6 cm)
Cutout Height Min. 82 7/8” (210.3 cm)
Max. 84 1/16” (213.5 cm)
Cutout Depth 24” (61.0 cm) min.
Electrical Requirements (2) - 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with grounded 3-
prong plug attached to product.
Maximum Amp Usage 9.9 amps (per unit)
Inlet Water Requirements (2) - 1/4” copper tubing inlet waterline; minimum 20 psi; maximum 120 psi
Overall Interior Capacity
((ppeerr uunniitt))
•Refrigerator 15.2 cu. ft. (.43 cu. meters)
•Freezer 5.1 cu. ft. (.14 cu. meters)
•Total Capacity 20.3 cu. ft. (.57 cu. meters)
Approximate Shipping Weight 575 lbs. (258.8 kg) - per unit
