Viking VCSB423D - CABINET AND PANEL INFORMATION - FULL OVERLAY MODELS; Flush Installation for Full Overlay Models

20
BB--BB
AA--AA
DDÉÉTTAAIILL AA--AA
DDÉÉTTAAIILL BB--BB
AA
AA
AA
42" W 42"(106.7 cm)
48" W 48"(121.9 cm)
CABINET AND PANEL INFORMATION - FULL OVERLAY MODELS
Full overlay models, (with 3/4” [1.9 cm], thick panels and custome handles locally supplied), fit flush in 25” (63.5 cm) deep (countertop
depth) cabinet openings with no protrusin into room except custom handles
