Viking VMOC206SS - PARTS LIST; ELECTRICAL PARTS

34
PARTS LIST
Refer to "IMPORTANT" described at end of parts list.
REF. NO. PART NO. DESCRIPTION Q'TY
ELECTRICAL PARTS
1- 1 FACCDA074WRE0 Power supply cord 1
1- 2 FFS-BA019/KIT
C/T fuse and monitor switch (V-5220D-070) assembly 1
1- 3 FPWBFA389WRKZ Noise lter 1
1- 4 QSW-MA085WRE0
Primary interlock switch/Thirdoor switch/Door sensing switch 3
1- 5 FH-HZA041WRE0 Thermistor 1
1- 6 QSW-MA085WRE0 Damper switch 1
1- 7 QFS-TA055WRZZ C/T fuse 1
1- 8 RTHM-A121WRE0 Oven & Convection thermal cut-out 150
ο
C 2
1- 9 RMOTDA192WRE0 Damper motor 1
1-10 RLMPTA093WRZZ Oven lamp 1
1-11 FDTCTA183WRK0 AH sensor assembly 1
1-12 QSOCLA021WRE0 Oven lamp socket 1
1-13 RMOTDA222WRE0 Turntable motor 1
1-14 RMOTEA300WRE0 Fan motor 1
1-15 RV-MZA377WRZZ Magnetron 1
1-16 RTRN-A799WRZZ Power transformer 1
1-17 RC-QZA331WRZZ H.V.capacitor 1
1-18 FH-DZA1S2WRKZ H.V.rectier assembly 1
1-19 QFS-BB008MRE0 Dummy fuse 1
CABINET PARTS
2- 1 GCABUB033WRPZ Outer case cabinet 1
2- 2 PCOVPA171WRP0 CSA barrier 1
2- 3 FDAI-A199WRY0 Base cabinet (Not Replaceable) 1
2- 4 GLEGPA019WRE0 Foot 4
2- 5 GCABDA088WRW0 Rear cabinet (Not Replaceable) 1
2- 6 LHLDKA009WRF0 Cord holder 1
2- 7 LBNDKA036WRP0 Capacitor holder 1
2- 8 FHNG-A320WRMZ Oven hinge (Lower) 1
2- 9 PHOK-A137WRFZ Latch hook 1
2-10 MLEVPA231WRF0 Switch lever 1
2-11 GCOVHA347WRP0 Turntable motor cover 1
CONTROL PANEL PARTS
3- 1 DPWB-A450DRKZ Control unit 1
3- 2 FPNLCB555MRK0A Control panel frame with key unit (VMOC206BK) 1
3- 2 FPNLCB556MRK0A Control panel frame with key unit (VMOC206WH) 1
3- 2 FPNLCB459MRK0A Control panel frame with key unit (VMOC206SS) 1
3- 2 FPNLCB558MRK0A Control panel frame with key unit (VMOC206BT) 1
3- 2 FPNLCB559MRK0A Control panel frame with key unit (VMOC206SG) 1
3- 2 FPNLCB560MRK0A Control panel frame with key unit (VMOC206GG) 1
3- 2 FPNLCB561MRK0A Control panel frame with key unit (VMOC206BU) 1
3- 2 FPNLCB562MRK0A Control panel frame with key unit (VMOC206LE) 1
3- 2 FPNLCB563MRK0A Control panel frame with key unit (VMOC206MJ) 1
3- 2 FPNLCB592MRK0A Control panel frame with key unit (VMOC206MS) 1
3- 2 FPNLCB565MRK0A Control panel frame with key unit (VMOC206VB) 1
3- 2 FPNLCB566MRK0A Control panel frame with key unit (VMOC206CB) 1
3- 2 FPNLCB593MRK0 Control panel frame with key unit (VMOC206TP) 1
3- 2 FPNLCB595MRK0 Control panel frame with key unit (VMOC206OG) 1
3- 2 FPNLCB594MRK0 Control panel frame with key unit (VMOC206CW) 1
3- 2 FPNLCB596MRK0 Control panel frame with key unit (VMOC206GM) 1
3- 2 FPNLCB597MRK0 Control panel frame with key unit (VMOC206SA) 1
3- 2 FPNLCB598MRK0 Control panel frame with key unit (VMOC206SE) 1
3- 2 FPNLCB599MRK0 Control panel frame with key unit (VMOC206IB) 1
3- 2 FPNLCB600MRK0 Control panel frame with key unit (VMOC206PM) 1
3- 2 FPNLCB601MRK0 Control panel frame with key unit (VMOC206RR) 1
3- 2 FPNLCB602MRK0 Control panel frame with key unit (VMOC206AR) 1
3- 2 FPNLCB603MRK0 Control panel frame with key unit (VMOC206PL) 1
3- 2 FPNLCB604MRK0 Control panel frame with key unit (VMOC206CH) 1
3- 2-1 JBTN-B165MRF0A Open button 1
3- 2-2 MSPRCA045WRE0 Open button spring 1
3- 3 LANGTA340WRW0 Control panel back plate 1
3- 4 MLEVFA057WRW0 Open lever 1
3- 5 NSFTTA042WRE0 Open shaft 1
3- 6 XEPS730P08XS0 Screw ; control unit mtg. 3
3- 7 XOTS740P12000 Screw ; control panel back plate mtg. 3
3- 8 LX-CZB019MRE0 Screw ; control panel mtg. 1
3- 9 XOTS740P12RV0 Screw ; power unit assy 1
