REF. NO. PART NO. DESCRIPTION Q'TY CODE
PARTS LIST
Note: The parts marked “
∆∆
∆∆
∆” may cause undue microwave exposure.
The parts marked “*” are used in voltage more than 250V.
∆
∆
OVEN PARTS
4- 1 PM100013 H.V. Capacitor band 1 AB
4- 2 PM110017 Chassis support 1 AE
4- 3 PM120014 Latch hook 1 AF
4- 4 PM120006 Switch lever 1 AD
4- 5 PM120013 Magnetron duct 1 AG
4- 6 PM110018 Fan blade 1 AC
4- 7 PM120011 Fan duct 1 AC
4- 8 ------------- Oven cavity (Not a replaceable part) 1 --
4- 9 PM110020 Waveguide cover 1 AV
4-10 PM120015 Turntable motor packing 1 AA
4-11 PM120012 Sensor duct 1 AG
4-12 PM120010 Cushion 1 AC
4-13 PM120009 Cushion 1 AA
4-14 PM110016 Noise filter angle 1 AE
ELECTRIC PARTS
1- 1 PM100021 High voltage capacitor 1 AQ
1- 2 PM100005 High voltage rectifier assembly 1 AM
1- 3 PM100018 Oven lamp socket 1 AE
1- 4 PM100022 Oven lamp 1 AE
1- 5 PM100024 Fan motor 1 AR
1- 6 PM100004
Monitor switch (V-16G-2C25) and fuse assembly (20A 250V AC)
1AF
1- 7 PM100019
Secondary interlock switch and door sensing switch (V-5230Q)
2AE
1- 8 PM100016 Magnetron temperature fuse 150½C 1 AE
1- 9 PM100017 Cavity temperature fuse 150½C 1 AF
1-10 PM100026 Magnetron 1 BE
1-11 PM100023 Turntable motor 1 AK
1-12 PM100025 Power transformer 1 BA
1-13 PM100002 Power supply cord 1 AM
1-14 PM100003 AH sensor 1 AW
1-15 PM100008 Noise filter 1 AW
CABINET PARTS
2- 1 PM110009 Base plate 1 BC
2- 2 PM110010 Foot 4 AB
2- 3 PM110007 Outer case cabinet 1 BC
CONTROL PANEL PARTS
3- 1 PM100001 Control unit 1
3- 2 PM100007 Control panel frame with key unit (DMOS200/CDMOS200) 1 AX
3- 2 PM100006 Control panel frame with key unit (VMOS200/CVMOS200) 1 AX
3- 3 PM110014 Open button (DMOS200/CDMOS200) 1 AE
3- 3 PM110013 Open button (VMOS200/CVMOS200) 1 AE
3- 4 PM120008 Open button spring 1 AA
3- 5 PM100015 LED sheet 1 AA
3- 6 PM100014 LCD holder 1 AA
3- 7 PM120026 Screw; 3mm x 10mm 3 AA
