26
Interchanging JetPaks-
Premium Series,Comfort
Series, and Design Series
Step 1: Put the spa in “Hold”, this will prevent the pump(s)
from activating (see Control Systems).
Step 2: Remove the head rest and Snap-Cap by lifting upwards.
CAUTION! WHILE PERFORMING STEPS 3&4 YOU
MUST USE THE BLACK MANIFOLD AREA AS THE
POINT OF CONTACT AS SHOWN IN THE PICTURE.
PRESSURE APPLIED TO THE FRONT FACE (ACRYLIC
PLATE) MAY CAUSE DAMAGE TO THE JETPAK
VOIDING THE WARRANTY
Step 3: While applying pressure downward on the manifold
push the manifold away from you toward the inside of the spa
to release the manifold from the wall clip assembly, then lift the
plate straight up to remove.
Step 4: Exchange JetPak
Step 5: Lower the manifold of the new JetPak carefully as to
align the lower valve assembly and gasket into the bulkhead
tting. Apply pressure downward as you pull the JetPak manifold
toward you to until the manifold is secured in the wall clip
assembly .
Step 6: Reattach the Snap-Cap and head rest.
Jets
Jet Types
A unique combination of the nest jets available are chosen
to optimally balance each JetPak with ideal performance and
massage intensity. You can achieve virtually limitless therapy
options by adjusting many of the jets for a custom experience.
Adjustable Jets Premium, Comfort and
Design Series
To adjust the water ow to Premium, Comfort and Design Series
JetPaks, turn the valve located in the lower portion of each JetPak.
• To increase jet water pressure, turn the valve handle counter
clockwise
• To decrease jet water pressure, turn the valve handle
clockwise To adjust the water ow to A, R & S Series jets in
the shell, turn the inner jet face.
• To increase jet water pressure, turn the jet face clockwise
• To decrease jet water pressure, turn the jet face counter
clockwise
JETPAKS & JETS
