3 Technical data
Model ViClean-I 100 ViClean-I 200
Supply voltage 220 - 240 V AC, 50 Hz
960 W * 982 W **Rated power consumption
* Input water temp.: 15±5 °C, flow rate
500 ml/min, ** with level 5 seat heating
Maximum power consumption 1344 W 1387 W
Batteries (2x) for remote control Type: LR03/AAA
Flush water consumption 4.5 l / 3 l
Outlet diameter 110 mmToilet
Outlet Horizontal outlet
Mode Flow heater
Water temperature 30 - 40 °C (5 stages)
Heating element output 480 - 1344 W
Safety device Type AB
Spray functions
Adjustable nozzle position 5 levels
Mode - Direct heating element
Air temperature - 25 - 45 °C
Warm air dryer
Heating element output - 100 W
Seat temperature - 30 - 38 °C (5 stages)Seat heating
Rated output of heating element - 22 W
Protection rating IPX4
Min. water pressure required: 0.1 MPa (dynamic)Water inlet pressure
Max. permissible water pressure: 1.0 MPa (static)
Water hardness Max. recommended water hardness
2.4 mmol/l (14°dH) without softening system
Water inlet temperature 10 - 35 °C
Ambient temperature for operation 15 - 40 °C
Dimensions (length x width x height) 595 mm x 385 mm x 400 mm
Weight 32 kg
EN
M.VILLEROY-BOCH.COM // V 2.0 // 04.03.2024 // 37524
17
