14
EnOcean multi-function 1-relay actuator (01796.1)
- Radio lighting point installed in a metal casing;
- Plasterboard walls with insulation of wool and aluminium foil;
- False ceilings made of metal or carbon fibre;
- Lead glass or glass with covering of metal, steel jewellery;
Warning: The following illustrates the situations that reduce the transmission/reception capacity of the radio devices.
BARRIER
Radio
signal
shadow
Radio signal penetration
Material Penetration
Wood, plastic, glass 90....100%
Bricks 65....95%
Concrete 10....90%
Metal, aluminium walls 0....10%
- Transmitter or receiver installed on the floor or in a niche in a wall;
- Moisture;
- Devices that transmit RF signals such as computers, audio and video appliances or dimmer switches for lamps: keep
at a distance of at least 0.5 m.
WALL
thickness 20 cm
WALL
thickness 60 cm
Low
attenuation
of the radio
signal
High
attenuation
of the radio
signal
