Vimar ELVOX 13F4 Installer's Guide

29
EN
2.9
Answer time
3.0
Conversation time
3.1
Self-start time
3.2
Lock time
3.3
Function 1 Time
to confirm the change.
Default: 654321
2.9 - Answer time
This is the interval of time, expressed in seconds, that the electronic unit waits from the end of the call signal until there
is an answer from the indoor unit. If there is no response within the "answer time", the electronic unit ends the call. If
the indoor unit answers before the set interval elapses, the electronic starts to count the conversation time.
Enter the new time with buttons
0
+
to
9
WXYZ
. Press to confirm the change.
Default: 30 s, minimum value 1 s, maximum value 255 s.
3.0 - Call time
This is the interval of time, expressed in seconds, that the electronic unit monitors from the moment that a call is
answered by the indoor unit. Once the interval has elapsed, the electronic unit ends the call. Enter the new time with
buttons
0
+
to
9
WXYZ
(in steps of 10 s). Press to confirm the change.
Default: 120 s, minimum value 10 s, maximum value 2550 s.
3.1 - Self-start time
This is the time, in seconds, of the duration of the self-start function. Once the interval has elapsed, the electronic unit
disconnects the indoor unit. Enter the new time with buttons
0
+
to
9
WXYZ
. Press to confirm the change.
Default: 10 s, minimum value 1 s, maximum value 255 s.
3.2 - Lock time
Activation time of the lock connected between terminals S+ / S- and +12V / SR.
Enter the new time with buttons
0
+
to
9
WXYZ
. Press to confirm the change.
Default = 1 s, minimum value 0 s corresponding to lock always off, maximum value 255 s.
3.3 - Function 1 time
Activation time of the device connected between terminals +12V / F1. Enter the new time with buttons
0
+
to
9
WXYZ
. For
the minimum value of 0.5 seconds. enter
0
+
. Press to confirm the change.
Default = 1 s.
3.4 - Function 2 time
Activation time of the device connected between terminals +12V / F2. Enter the new time with buttons
0
+
to
9
WXYZ
. For
the minimum value of 0.5 seconds. enter
0
+
. Press to confirm the change.
Default = 1 s.
3.5 - D.O. (door open) send time
Normally an entrance panel sends over the bus a notification of the D.O. (Door Open) input status only when it
changes. The Master entrance panel sends the global status (at least one door is open or all the doors are closed)
only when it changes. In some situations it is desirable for this to be done periodically. Using buttons
0
+
to
9
WXYZ
enter the send time in minutes.
0
+
to disable. Press to confirm the change.
Default = disabled, 1' minimum, 90' maximum
3.6 - External volume
THIS is the voice volume of the speaker attached to the electronic unit, which can be adjusted through 8 steps. Press
to enable changes to the volume setting. Press the buttons to increase or reduce the volume. Press
to confirm the change.
Default = 3
3.7 - Internal volume
THIS is the volume of the speaker fitted to the electronic unit, which can be adjusted through 8 steps. Press to
enable changes to the volume setting. Press the
and buttons to increase or reduce the volume. Press
to confirm the change.
Default = 3
3.4
Function 2 Time
3.6
External volume
3.5
D.O. Send Time
3.7
Internal volume
