PROGRAMMING THE SWITCHBOARD PARAMETERS
The switchboard is delivered with an "already inserted" basic program , which can be modified according to the instructions to
follow. The programming is necessary if the pre-programmed parameters do not satisfy the installation requirements.
A) Entry to programming mode using the front switchboard keypad
Press push-buttons "R" and "4" simultaneously on the front keypad.
When a series of symbols "########" is displayed on the screen, digit code "123". If the above sequence has been correctly
performed "PROGRAM" will be displayed on the LCD screen. If this is not the case, repeat the entire procedure.
Once you have entered the programming mode use the bell button to scroll the following parameters and the numerical
keys to modify the associated values. In the case of error, only use the numerical keys to correct the value entered. Press
push-button to confirm any changes. On completion of programming, press push-button and then R to exit the tech-
nical programming function.
Parameters may be programmed and consulted as and when required.
Parameter settings are stored in the memory even in the event of power failure until next edited.
Same parameter as that of the entrance panel and internal product programming (interphone-monitor).
Switchboard technical parameters table
Parameter Minimum value Maximum value Set value Description
Initial user 1 99999999 00000001 only for building complex
Final user 1 99999999 99999999 only for building complex
System Number 1 99999999 00000000 It assigns a code to the switchboard
(for direct call from entrance panel or
remote programming).
-------------- 1 99999999 00000000 Not used
Technical prg. key 0 9999 00000123 Technical programming access code
Dis switch keypad 0 9999 0000027 Switchboard keypad disable code
* Number of digits 4 8 000004 4/8 digit selection
Language 0 1 000000 0 = Italian language
1 = English language
Entr. Pan. Prefix 0 99 000099 The two digits indicate the call function
from the external panel to the switchboard
Lock abilit 0 1 00001 Enables transit of door lock activation
(0 = NO, 1 = YES)
Camera abilit 0 1 00001 Indicates presence of switchboard
(0=NO, 1=YES).
Sound enable 0 2 00002 0= Disable all chimes
1= Enables the internal call chime
2= Enables the external and internal call chime
Ring time enable 0 1 00001 Sound enabling for the clock signal
Function Vis. enable 0 1 00001 Function display enabling
Switchoard dialling code
1 99 00000000 The two digits indicate the call function from
switchboard and switchboard
Call rip. number 1 255 00003 Enables the switchboard call chime for the
programmed intervals
Conversation time 1 255 00012 Maximum conversation time (time = value
x 10 seconds; 12 = 120 seconds)
Ring duration 1 255 00001 Call signal activation time
(time = value x 1 second)
Answer time 1 255 00030 Relay delay time
(time = value x 1 second)
F1 time 1 255 00001 EM1 auxiliary function activation time
(time = value x 1 second)
F2 time 1 255 00001 EM2 auxiliary function activation time
(time = value x 1 second)
Lock time 2 255 00001 Door lock activation time
(time = value x 1 second)
Printer Set 0 255 00001 Printer setup
Enables call transit 0 1 00000000 Enables external call transit: YES - NO
Reserved parameter 0 1 00000000 Reserved parameter
press R to exit
