OPERATION
DISPLAYING THE TIME - DATE - WAKE UP TIME-TABLE
The time is always displayed at the top on the right hand side of display.
To display other data press push-buttons R+2 (or R+Number transf. [8->8]), and the following message will appear:
DATE: 14/02 15:30:35
AL.RING: 12:30 & 18:30
ACTIVATION OF LOCK RELEASE, F1, F2 AND OF THE ACCESSORIES FUNCTIONS F6, F7, F8:
Pressing the "CHIAVE" (Key) push-button the following menu will appear:
SELECT OPEN?
(0=LOCK; 1=F1; 2=F2; 6=F6; 7=F7; 8=F8).
Pressing a numerical push-button the respective command is activated. Besides the normal door lock ("O" push-button) it is
possible to activate Function 1 (push-button 1) and F2 (push-button 2). The activation in this case works on proper pin and
send downward the corresponding digibus command (to possible main entrance panels).
Pressing, on the contrary, the numerical push-buttons 6, 7 or 8 it is to send an auxiliary command (F6, F7 or F8) to a possible
auxiliary relay (type 170D) in order to allow other possible external functions (stair light, irrigation etc.) to be activated (other 5
external functions (max) may be activated besides the door lock).
In all cases during the activation time the "key" icon is simultaneously activated.
SWITCHBOARD LOCK BY MEANS OF A SOFTWARE KEY
The complete keypad lock may be made by inserting a password. This password must be previously stored in the technical
parameters (parameter = "CHIAVE BLOC SW.") with a number included between 1 and 32000.
To activate the lock using the software key, press push-buttons "R+1" simultaneously. A request for password appears:
Cod. Bloc. Tas. ?
--------
Enter then the password and press C (default password=27)
The switchboard keypad is now blocked. The display shows the message "!BLOCCO CHIAVE!" (locked keypad) . Transit and
calls toward the switchboard are in any case completely active.
To release it repeat the same procedure repeating the same password.
To modify the password enter the parameter programming (pressing "R+4" )and enter the parameter "Chiave Bloc. Sw." using
the wanted password value.
NOTE: the lock operates even during a mains failure.
CONFIDENTIAL: If you forget the password enter the programming mode by using push-buttons on the lower side. Press
PS2 and release it , press and keep pressed PS1 until the message PROGRAM appears and check the password in the analog
parameter in the memory.
QUEUE OF STORED CALLS:
The backed-up memory keeps the latest 30 requests from internal units (calls and/or F1 and/or F2 and/or APERTU-
RA_SERRATURA (lock release) according to the programming) complete with the reception time. In this case a special event
counter with icon (box with arrow) signals the number of events in the memory on the display (and the proper led switches on).
Recording time 14:30 00000000 14:56:30
Chiam.citof.N 00123456 03
Type of command and Counter for number of events
number of the calling in memory (it is alternated with
internal unit. the icon "commandi in memoria"
(command in memory).
You can scroll the events by pressing push-button "MEM". Pressing push-button "trasferimento numero " (number tansfer) (8-
>8) the number is got from the memory and displaced onto the call display, so as it can be called upon request. The event
counter for consequence decreases the event number.
To blank the memory completely and automatically press push-button and keep it pressed for nearly 3 seconds. A short
tone and the event counter cancellation will confirm the complete buffer blanking.
