Vimar ELVOX SL24.T User Manual

4
SL24.T
EN
Terminal block functions
Terminal Description Rated data
T1 Transformer secondary connection
24 Vac
T2 Transformer secondary connection
21 Opening motor
24 Vdc 80 W
22 Closing motor
12
Auxiliary radio/courtesy light negative
output
24 Vdc 120 mA
1 Accessories positive
14 Gate open warning light negative output
24 Vdc 120 mA
1 Accessories positive
1 Accessories positive
24 Vdc 500 mA
0 Accessories negative
10 Flashing light negative
24 Vdc 15 W max
11 Flashing light positive
99 Common inputs
51 Step by step (N.O.)
52 Pedestrian (N.O.)
Terminal Description Rated data
99 Common inputs
61 Stop (N.C.)
62 Photocell when closing (N.C.)
63 Photocell (N.C.)
31 Limit switch 1
99 Common inputs
32 Limit switch 2
- Aerial earth
ANT Aerial signal
41
-E
+E
BAT
U
2
TCA
PROG
MRX
C
N9
1
5
A
F1 (ATO)
S
E
C
T1
T2
O
N
1
2
3
4
5
6
7
8
9
10
DIP1
FM1
VS
V
PWR
PRG
51
F2 (5X20)
F3.15 A
CNRX
U1
99
52
63
51
99
61
62
31
_
ANT
SL24.T
21
22
12
14
1
0
10
11
1
31
99
32
32
51
52
61
62
63
ENCA
ENCB
- 230 Vac
- 120 Vac
N
L
PED
P.P.
PHC
PH
STOP
COM
COM
M
OPEN M
CLOSE M
RAU
RAU-
SCA-
SCA
24V+
24V-
BLINK-
BLINK+
24V+
SW1
SW2
COM
ZBA6

Vimar ELVOX SL24.T Specifications

General

Brand	Vimar
Model	ELVOX SL24.T
Category	Control Panel
Language	English
