Gasifying boilers VIGAS
Functionality of each button are composite and their functionality deppends accompanying
description on display and from manufacture settings.
3.6 Symbols
1. Real time indication.
2. Indication of current boiler values.
Modification ▲ or .
3. Indication od discharge fan, lambda sensor, gases
thermometer
4. Indication of nominal boiler output when switched off.
5. Graphically indicated hydraulic scheme o
f
connection.
6. Indication of boiler status.
Pic.
7
Boiler Storage tank External boiler
Boiler „ON“
ON
DUOMIX Heating circuit
Boiler „OFF“
OFF
DUOMIX with
servomotor
Indoor
thermostat
Heating
ON
Pump
3-way
thermostatic
valve
Burning
73
0
C
Discharge fan LADOMAT
Afterflaming
52
0
C
Lambda
λ
Fan
End of burning
END
Thermometer
T
Fan change
output
Indoor
termostat
decay
Error indication
value
x
Open flap servo 50%
Adding fuel
Minimal value
of gases
min
Maximal value
of gases
max
Temperature
settings
Parameter
settings
Time setting
Error
messages
Program
Konfiguration
informations
Service
message
