Most thermostats allow you to remove the main unit
and provide access to a wall plate which holds the
wiring terminals, you can take off the thermostat by
grasping and gently pulling. Some thermostats may
have screws, buttons, or clasps.
Take a picture of your existing wall plate’s wiring
and save it for reference. Make sure you can read
the wire terminal labels.
Note: Do not remove any wires from your thermostat
at this time!
Remove your old thermostat from the wall-plate
Step 3
Take a picture of the wiring
Step 4
Label the wires
Step 5
Label the old wall plate with our new thermostat
labels from packing box.
G
C
Y
R
06
