3 Starting Up the Video Station
The Turbine Video Station features an embedded web interface, which allows users to log in via a
standard web browser.
L Software upgrade procedure for the video station is the same as for the audio stations in the
Turbine series. For further details, see A100K11194 Turbine IP Stations Technical Manual.
To start up the station, your PC and the IP station have to be connected together via a PoE switch
using network cables:
1. Connect the PC to the PoE switch
2. Connect the PoE port on the IP station to the PoE switch
When the Turbine Video Station is connected to the network, the IP address of the station is
automatically obtained in one of two ways:
1. An IP address is obtained from a DHCP server if there is one.
2. If there is no DHCP server, an IP address in the range 169.254.x.x will be assigned.
To make the station speak its IP address:
● Press the call button on the station
- when the station is not registered yet
At commissioning, the IP Video station needs to be congured to enable it to be used as:
● Station subscribed to an AlphaCom server
● SIP station
● Pulse station
Figure 4 Turbine Video AlphaCom/Pulse/SIP System
AlphaCom XE Server/Exchange
AlphaComXE7
Turbine TCIV-2
Turbine TCIV-6
Desktop Video Display Station
Turbine TCIV-3
iPBX (SIP domain)
SIP Video Phone
ITSV-1 Video Phone
IP Network
