6. HOW TO REVERSE THE DOOR SWING
This wine cellar has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the
opening direction, please follow the following reversal instructions:
6.1 DESIGN 1 – For built-under models
1. Remove the ventilation grille
○
2 and the adjustable ventilation grille
○
1 by unscrewing the
screws
○
3 &
○
4 . (Fig. 1)
NOTE: For some models without adjustable ventilation grille, the step is not needed.
2. Remove the bottom hinge
○
5 by unscrewing the four lock screws
○
6 . Be careful to hold
the glass door firmly after removing the screws. (Fig. 2)
3. Gently pull down to remove the glass door from the right top hinge and place it on a padded
surface to avoid the risk of damage. Then remove the right top hinge
○
9 . (Fig. 4)
4. Unscrew and transfer hinge pin
○
7 and/or door stopper
○
8 of the bottom hinge to the
opposite side. (Fig. 3)
5. Pop out the cover caps on the left side of cabinet and use them to cover the screw holes on
the right hand side.
6. Screw the alternative left top hinge
○
11 , included in the fittings, on the left hand side of
Note: All parts removed must be saved to do the reinstallation of door.
