7.5 REPLACING THE LED LIGHT
1. Remove all shelves.
2. Remove the LED light cover
○
1 by fingernail.
3. Pull down to remove the LED light PCB and replace it with a new one.
IMPORTANT: Pls insert the new LED light PCB with correct polarity!
2
1
7.5A REPLACING THE LED LIGHT
1. Remove all shelves.
2. Remove the screw
○
1 (For the new design the step of removing the screw is not needed).
3. Pull out the light cover
○
2 by fingernail and then you can replace LED light PCB.
IMPORTANT: Pls insert the new LED light PCB with correct polarity!
2
3
41
