Vinten HD-VRC - HD-VRC Computer Connections; Previous Version Connections

10
HD-VRC Computer Connections
1 2 3 4
5 6 7 8
10
5 Component video sockets
6 SDI (IN/OUT) video sockets
7 PS2 keyboard socket
8 Ethernet socket
9 VGA socket (to touch-screen)
10 AC power switch
1 RS422 serial sockets (COM3&4)
2 USB sockets (x2)
3 RS232 serial sockets (COM1&2)
4 AC power socket
Previous Version
