Joystick Panel Controls
1
2
3
4
5
7
6
1 X/Y/Height joystick control*
2 CCU black level control*
3 CCU iris control*
4 Function buttons*
5 “on air” indicator
10
8
9
6 Pan/Tilt/Zoom joystick control
7 Camera selection buttons and tally indicators (x16)
8 Camera control buttons (Cut/Fade/Stop)
9 Fade time control
10 Focus control
*Control and button functions
are not present on all panel
models. See....
