VIOMI S9 - Component Details; 2-in-1 Dust Compartment with Water Tank; Automatic Dirt Disposal Station

04
Inlet
Water Tank
Dust Compartment
Dust Compartment release buon
Dust Compartment clamp
Mop holder
Mop
Filter screen clamp
Filter screen
2-in-1 Dust Compartment with Water Tank
Top cover
Remove the top cover.
Mount/remove dust bag.
Dust bag holder
IR lens
Recharging/automatic dirt
disposal probe.
Recharging/automatic dirt
disposal sensor.
Dust collection port.
Collect trash in the
machine to the dust bag
through collecting port.
Automatic dirt disposal (Two-in-one for dust collection
and charging)
