Manual VIPA System 200V Chapter 2 Analog input modules
HB97E - SM-AIO - Rev. 12/32 2-51
The assignment of a function-no. to a certain channel happens during
parameterization. The function-no. 00h does not influence the function-no.
stored in the permanent parameterization data.
Assigning FFh deactivates the according channel.
No. Function Measurement range / representation Connection
00h Does not affect permanently stored configuration data
28h Default value
Voltage
±10V
Siemens S7 format
(two’s complement)
±10V
9.9 ... 10V (27371 ... 27648)
1)
-9.9...9.9V= rated range (-27370... 27370)
-10V ... -9.9V (-27648 ... -27371)
1)
(1), (2)
29h
Voltage
±4V
Siemens S7 format
(two’s complement)
±4.70V /
4.70V = max. value before over range (32511)
-4...4V = rated range (-27648...27648)
-4.70V = min. value before under range (-32512)
(1), (2)
2Ah
Voltage
±400mV
Siemens S7 format
(two’s complement)
±470mV /
470mV = max. value before over range (32511)
-400...400mV = rated range(-27648...27648)
-470mV = min. value before under range (-32512)
(1)
2Ch
Current
±20mA
Siemens S7 format
(two’s complement)
±23.51mA /
23.51mA = max. value before over range (32511)
-20...20mA = rated range (-27648...27648)
-23.51mA = min. value before under range (-32512)
(1), (3)
2Dh Current 4...20mA
Siemens S7 format
(two’s complement)
1.185 .. +22.81mA
/
22.81mA = max. value before over range (32511)
4...20mA = rated range (0...27648)
1.18mA = min. value before under range (-4864)
(1), (3)
58h
Voltage
±10V
(two’s complement)
±10V
9.9 ... 10V (9901 ... 10000)
1)
-9.9 ... 9.9V rated range (-9900 ... 9900)
-10 ... -9.9V (-10000 ... -9901)
1)
(1), (2)
59h
Voltage
±4V
(two’s complement)
±4.95V /
4,95V = max. value before over range (4950)
-4...4V = rated range (-4000...4000)
-4.95V = min. value before under range (-4950)
(1), (2)
5Ah
Voltage
±400mV
(two’s complement)
±495mV /
495mV = max. value before over range (4950)
-400...400mV = rated range (-4000...4000)
-495mV = min. value before under range (-4950)
(1)
5Ch
Current
±20mA
(two’s complement)
±25mA /
25mA = max. value before over range (25000)
-20...20mA = rated range (-20000...20000)
-25mA = min. value before under range(-25000)
(1), (3)
5Dh Current 4...20mA
(two’s complement)
0.8 .. +24.00mA
/
24.00mA = End over range (20000)
4...20mA = rated range (0...16000)
0.8mA = min. value before under range (-3200)
(1), (3)
FFh Channel not active (turned off)
1) depends on calibration factor and is not guaranteed.
Note!
The module is preset to the range "±10V voltage" in S7 format from
Siemens.
Function-no.
allocation
