Optional Sensors, 4-Pin White Plug

There are two optional sensor input ports. Optional sensors which can be used are field, tilt, ultra-

sonic, or glass breakage. Alarm trigger inputs shorter than 0.8 seconds will trigger the Warn Away

response, while inputs longer than 0.8 seconds will trigger full alarm sequence and report Zone 4

or Zone 7 for multiplex input.

NNOOTTEE::

The ground for the optional sensors is now controlled by the GWA.
