Viper VR-6000 - Controls and Control System; Control Panel Components

INSTRUCTIO NS MANUA L
CONTROLS AND CO NTROL SYSTEM
Refer to Fig 5:
(A1) Low press ure gauge for A/C system
(A2) High pressure gauge for A/C system
(A4) Press ure gauge for storage tank
(A6) Em ergency/alarms panel
(A7) Display
(A8) Keypad controls
(A9) Operations selector panel
A1
A2
A9
A4
A6
A7
A8
Fig.5:Control Panel
