DRUM KIT ASSEMBLY

2. Attach the feet to the Drum Frame

(g.1)

(g.1)

3. Unfold the Drum Frame arms as shown

(g.2)

(g.2)

(g.3)

4. Attach the cymbal arms to the drum frame

indicated positions .

(g.3)

(g.4)

CRASH

RIDE

HI-HAT

5. Attach the cymbals to the cymbal arms as

shown. Place the n on the cymbal arm between

the anges on the cymbal as shown.

(g.4)
