VIRTUFIT CTR 1.2i - Page 26

EN
VirtuFit CTR 1.2i Crosstrainer
26
PARTS LIST
# DESCRIPTION QTY
61 Washer 1
62 Left collar housing 1
63 Collar ball 1
64 Collar housing 2
65 Right collar housing 1
66 Washer 1
67 Chain wheel 1
68 Belt 1
69 U bracket 2
70 Bearing 2
71 Axle 1
72 Nut M10 2
73 Nut M10 2
74 Flywheel 1
75 Nylon nut M8 2
76 Tension spring 1 1
77 Crank 1
78 Bolt 1
79 Bracket 1
80 Open-end wrench S13 14 15 1
81 Hex wrench S6 1
82 Hex wrench S8 1
83 Open-end wrench S17 18 19 1
84 End cap 2
85 Arc washer D8Xφ16X1.5XR30 4
86 Magnetic board 1
87 Tension spring 2 2
88 Plastic lattice 1
89 Magnet 4
90 Hexagon nut M6 2
# DESCRIPTION QTY
91 Hexagon bolt M6*20 3
92 Idler 1
93 Hexagon thin nut M10*1.0*2 1
94 Spring washer d6 2
95 Washer d6 2
96 Srap ring d12 2
97 Axle of magnetic board 1
98 Hexagon nut 1
99 Adapter 1
100 Bottle holder 1
101 Crosshead screw M5*15 2
102 Bottle 1
103 Washer d5 4
104 Sensor 1
