VIRTUFIT CTR 1.2i - Parts List

EN
VirtuFit CTR 1.2i Crosstrainer
25
PARTS LIST
# DESCRIPTION QTY
01 Computer 1
02 Screw M5 4
03 Pulse 2
04 Middle Handlebar 1
05 Screw ST4x19 2
06 End cap φ25 2
07 Small cover 1
08 Bolt M8x30 2
09 Arc Washer D8 4
10 Foam grip 2
11 Handlebar ( L / R ) 2
12 Foam grip 2
13 End cap φ28 2
14 Stopple φ12.6Xφ6 2
15 Upright post 1
16 Wire 1
17 End cap S13 2
18 Bolt M8x16 2
19 Washer D8Xφ32X2 2
20 Bushing φ32Xφ19X28 4
21 Bolt M8x40 4
22 Arc washerD8Xφ20X1.5XR30 8
23 Domed Nut M8 8
24 Plastic insert 2
25 Lower handlebar ( L / R ) 2
26 Bolt M8x16 4
27 Knob M10 4
28 End cap S17 6
29 Bolt M10x60 2
30 Bushing φ14x12.5Xφ10.1 8
# DESCRIPTION QTY
31 Washer D10Xφ20x2 4
32 Nylon nut M10 8
33 Carriage Bolt M8X60 4
34 End cap φ50 2
35 Front stabilizer 1
36 Rear stabilizer 1
37 End cap φ50 1
38 Sensor 1
39 Tension control cable 1
40 Main frame 1
41 End cap J40X25 4
42 Pedal tube ( L / R ) 2
43 Bolt M10X50 4
44 Pedal 2
45 Bolt M10X50 2
46 Bolt ( L / R ) 1 / 2 2
47 Arc Washer D17 2
48 Bushing φ24X20Xφ16.1 4
49 U bracket 2
50 Spring washer 1 / 2” 2
51 Nylon nut ( L / R ) 1 / 2” 2
52 End cap S19 2
53 Power line connection 1
54 Crosshead screw M5*15 1
55 Motor 1
56 Crank cover 2
57 Crosshead screw ST4.2*16 5
58 Crosshead screw ST4.2*19 12
59 Chain cover ( L / R ) 1
60 Nut 1
