VirtuFit CTR 1.2i Crosstrainer
6
STEP 2
• Connect the Sensor 16 and 38, x the Upright Post (15) with the Main Frame (40) with Nut (27) Arc
Washer (22). Note: Tighten the Screw (27) and the Arc Washer (22) very tight.






03&6
G53&6
ASSEMBLY INSTRUCTIONS
