EN
VirtuFit CTR 1.2i Crosstrainer
9
STEP 5
ASSEMBLY INSTRUCTIONS
• Connect Handle Pulse Wire (4a) and (4b), then connect Sensor wire (16) to the Computer (1b); x the
Computer (1) onto the Upright Post (15) with Screw (2) and Washer (103).
• Attach the Bottle Holder (100) to the Support Tube (15) with Crosshead (101).
• Then, put the Bottle (102) in the Bottle Holder (100).
• Place the end cap (17) and (28) on the bolts as pictured above.
NOTE! Make sure that all nuts and bolts are tight before you start training. The end cap of the front
stabilizer tube is movable, making it easier for you to move the crosstrainer.
D
/
5
63&6
63&6
63&6
D
E
03&6
