PARTS LIST
# Description Qty
01 Main frame 1
02 Front bottom tube 1
03 Rear bottom tube 1
04 Handlebar post 1
05 Fixed handlebar 1
6 L/R Handlerbar Each 1
7 L/R Swing tube Each 1
8 L/R Pedal support Each 1
09 End cap 2
10 Hex screw M8x40xL12 2
11 Roller 2
12 Flat washer D8x Ø16x1.5 14
13 Nylon nut M8 6
14 Hex nut M10 4
15 Adjustable foot 4
16 Arc washer d8x2x Ø25XR39 4
17 Hex socket screw M8xL58 4
18 Spring washer D8 14
19 End cap 2
20 Crank 2
21 Wave washer Ø17x Ø23x0.3 4
22 Plastic bushing Ø24x16x Ø16.1 4
23 L/R Pedal tube joint Each 1
24 D-shape washer 4
25 Spring washer D10 4
26 Hex socket screw M10x20 4
27 Screw M5x10 4
28 a/b Protective guard Each 2
29 Hex bolt M10x55 2
30 Flat washer D10x Ø20x2 4
31 Nylon nut M10 4
# Description Qty
32 Bushing Ø18x Ø10x11 4
33 Hex screw M8x45 6
34 L/R Pedal Each 1
35 Screw ST4.2x18 10
36 L/R Protective guard Each 2
37 Screw Ø12xM10x80 2
38 Flat washer D12x*24x1.5 2
39 Bushing Ø12x Ø32x23 6
40 Bushing Ø16x Ø31x23 6
41 Screw ST3.5x12 4
42 a/b Protective guard Each 2
43 Arc washer D8x Ø19x1.5xR30 4
44 Carriage bolt M8xL45 4
45 L/R Foam grip Each 1
46 Round cap crossbar 2
47 Console 1
48 Roundcap handlebar 2
49 Handle pulse sensor 2
50 Foam grip 2
51a/b Protective guard Each 1
52 Screw M4x10 4
53 Allen bolts M8x16 10
54 Pulse wire 2
55 L/R Pedal cushion Elk 1
56 Long axle 1
57 Sensor wire 1
58 Protective guard 1
59 Extension sensor wire 1
60 Flat washer D10x Ø20x2 4
61 Adapter 1
62 Kettle holder 1
63 Screw 2
64 Flat washer 2
