UltraReceiver User Manual
Specification
Issue No: 3 Page: 9
Ref: ULRX-ASUM-700X Copyright © 2018 Vislink plc
Temperature (operating):
C to 50˚C [3F to 122˚F]
Humidity (non-condensing):
95%
Diversity Receiver 2-RF input to 4-RF input upgrade option.
Figure 3-1 Input / Output Connections
Summary (details in Section 3.13):
4 x UHF input 70MHz to 860 MHz combined using Maximal Ratio Combining (MRC)
1 x ASI input (complies with ISO/IEC 13818-2 188byte mode)
1 x Frame lock input (Black/Burst or Tri-level)
4 x Video outputs UHD or 1x HD
1 x ASI output (complies with ISO/IEC 13818-2 188-byte mode)
2 x Audio channel outputs (analogue or digital)
Data channel output
Video over IP connection (Ethernet RJ45)
