Vislink UltraReceiver User Manual

UltraReceiver User Manual
Specification
Issue No: 3 Page: 8
Ref: ULRX-ASUM-700X Copyright © 2018 Vislink plc
 4 x UHF inputs, 70-860MHz. Switchable LNB power.
 ASI input (ISO/IEC 13818-2 188 bytes) for ASI in.
 Frame Lock input (black/burst or HD tri-level)
 Camera Control / Mpeg data channel interface on 6-pin Lemo (CTRL/DATA)
 10/100/1000 Ethernet connection for Video-over-IP connections
 Up to 4x embedded audio outputs
 ASI output (ISO/IEC 13818-2 188 bytes)
 Audio output on two 3-pin XLRs (channel 1) and 5-pin Lemo (channel 2)
 4 x 3G-SDI SMPTE-424M
 4 x HD-SDI SMPTE-424M
 480i@29.97 (*Future option)
 576i@25 (*Future option)
 720p@50/59.94/60
 1080i@50/59.94/60
 1080p@23.98/24/25/29.97/ 30/50/59.94/60
 2160p@23.98/24/25/29.97/ 30/50/59.94/60
 MPEG-1 Layer 1 20-bit 48kHz (*Future option)
 MPEG-1 Layer 2 20-bit 48kHz (*Future option)
 SMPTE 302M 20-bit 2 channel 48KHz 8ms frame
CAUTION: Keep the side-vents clear to allow adequate airflow.
 1U height, half rack width
 210mm [8.3"] x 350mm [13.8"] Deep (excluding connectors)
 1.2kg/2.6 lbs. (approximate)
 100 to 240VAC; 100W (approximate, depending on configuration)
 AC input option 90 VAC to 264 VAC 50Hz to 60Hz; max current 1A(rms) DC input
option 9 VDC to 36 VDC (-ve chassis earth); max current 10A 70Watts excluding the
downconverters requirements.
 100W max allowing for downconverters and cables.
