Vislink UltraReceiver User Manual

UltraReceiver User Manual
Specification
Issue No: 3 Page: 7
Ref: ULRX-ASUM-700X Copyright © 2018 Vislink plc
DVB-T: QPSK, 16QAM & 64QAM; 6, 7, & 8MHz
LMS-T: QPSK & 16QAM; 10 & 20MHz
LMS-T: Variable Bandwidth:
Single Pedestal:
 3, 4, 5, 6, 7, 8, 10, 12 MHz
Dual Pedestal:
 4, 6, 8, 10, 12, 14, 16, 20 & 24 MHz
HEVC (H.265)
AVC (H.264)
MPEG-2 (H.262) (*Future option)
AAC (*Future option)
MPEG-1 (*Future option)
AES/Dolby pass through (*Future option)
 480i@29.97 (*Future option)
 576i@25 (*Future option)
 720p@50/59.94
 1080i@50/59.94
 1080p@23.98/24/25/29.97/ 30/50/59.94
 2160p@23.98/24/25/29.97/ 30/50/59.94
 UHD
 Main 10-8/10bits 4.2.0/4.2.2
 1.0-90Mbps
 HD
 Main 10-8/10bits 4.2.0 /4.2.2
 1.0-90Mbps
 SD (*Future Option)
 4.2.0 Main 0.5-90Mbps
 4.2.2 Main 2.0-90Mbps
