UltraReceiver User Manual

Specification

Issue No: 3 Page: 10

75Ω BNC type chassis connector:

NOTE: If only two inputs are licensed, inputs three & four are not operational.

NOTE: When operating in Dual Pedestal LMS-T RF three & four are used for connection to

the two down convertors (this is different to the L2174 configuration).

 UHF input 70MHz to 860MHz.

 Receiver performance meets or exceeds ES 202 239 in DVB-T mode (typical

sensitivity -93dBm @DVB-T QPSK 1/2)

For configuration, please refer to the HOME > DEMODULATOR Menu.

NOTE: These inputs can have +20VDC output (set in Unit/LNB Power) to power the external

down converter; limited to 400mA per connector, short circuit protected.

75Ω BNC chassis mounted socket. Complies with ISO/IEC 13818-2 – 188-byte mode.

ASI input to the Decoder.

75Ω BNC chassis mounted socket.

Optional lock decoder output for both SD & HD video:

 SD Mode: Composite Black and Burst input for timing reference.

 HD Mode: Supports HD tri-level sync reference input.

 Delay increased by 0 – 40ms.

75Ω mini BNC chassis mounted socket.

Output #1 - #4. Two independent outputs for

 4 x 3G HDSDI:

 ITU-R BT.656 / ANSI/ SMPTE 259M @ 270Mb/s. for UHD / 4K quadrant o/ps

 HDSDI:

 SMPTE 292M @1.485Gbps

For supported video formats, see Section 3.3.

75Ω BNC chassis mounted socket. Complies with ISO/IEC 13818-2 – 188-byte mode.

ASI output from the Demodulator or ASI input for decoding by an external decoder or

chaining to another UltraReceiver.
