D-302754 27
(First display)
READY 00:00
WALK TEST
USER SETTINGS
ENTER CODE
1. NEW INSTL CODE
2. ENROLLING
4. DEFINE PANEL
[installer code]
INSTALLER MODE
3. DEFINE ZONES
5. DEFINE COMM
INSTALLER MODE
8. DEFINE OUTPUTS
pulse time 2s
pulse time 30s
pulse time 4m
pulse time 2m
PGM PULSE TIME
(*)
DEFINE PGM
disable
turn on
pulse active
turn off
PGM: BY DELAY
disable
turn on
pulse active
turn off
disable
turn on
pulse active
turn off
toggle
PGM: BY KEYFOB
disable
turn on
pulse active
turn off
disable
turn on
pulse active
turn off
disable
turn on
pulse active
turn off
(*)
PGM: BY ZONES
x - zone Z: _ _
(ENTER ZONE NUMBERS)
disable
turn on
pulse active
turn off
toggle
(SELECT BY OR )
a - zone
c - zone b - zone
by line fail no
by line fail yes
PGM: BY LINE FAIL
PGM: BY DISARMPGM: BY ARM AWAY PGM: BY ARM HOME PGM: BY MEMORY
(**)
PGM GENERAL DEF
DEFINE INT/STRB
internal siren
strobe
Select “start”/”stop”and
enter the desired time.
TIME - 00:00 A
start - HH:MM A
stop - HH:MM A
LOCKOUT TIME
Figure 4.8 - Define Outputs Flow Chart
*
Upon selecting any one of the 3 options (zone a, b and c) you may enter a zone number and then select "disable", "turn on", "turn
off", "pulse active" or "toggle".
**
The currently saved option is displayed with a dark box at the right side. To review the options, repeatedly click
button
until the desired option is displayed, then click
(a dark box will be displayed at the right side).
4.9 DEFINE VOICE
DEFINE VOICE is optional - applicable only in
PowerMaxComplete that includes "voice" feature.
4.9.1 Record Speech
This mode allows you to record short-duration speech
messages for the following purposes:
• House identity is a message announced automatically
when events are reported to private telephones.
• 4 User Names can be recorded and assigned to users
numbered 5-8. In case of event, the relevant user
name will be added to the message that will be
reported via the telephone.
• 5 custom zone names can be recorded and assigned
to specific zones. These names are useful if none of
the 26 fixed zone names are found suitable for a
certain zone (see Fig. 4.3).
• Edit custom zone names enables you to edit the
names that have been assigned to zones.
The recording process is shown below.
4.9.2 Voice Box Mode
This mode allows you to determine whether two-way voice
communication is to be sounded either via the optional
external speech box, via the PowerMaxComplete, or via both.
Options: No Voice Box, Voice Box Only or Voice Box
Mixed.
