D-302754 35
Table A1 – Common Area Definitions
Common area zone
types
Definition
Perimeter
• Acts as defined only after the last assigned partition is armed AWAY or HOME.
• In case that one of the partitions is disarmed, an alarm initiated from this zone is
ignored for all assigned partitions.
Delay zones
• Delay zones will not trigger an entry delay unless all assigned partitions are armed. It
is, therefore, not recommended to define delay zones as common areas.
Perimeter follower
• Act as defined only after the last assigned partition is armed AWAY or HOME.
• In case that one of the partitions is disarmed, an alarm initiated from this zone is
ignored for all assigned partitions.
• In case that one of the common area assigned partitions is in a delay state (and the
other partitions are armed), the alarm will behave as a perimeter follower for this
partition only. The event will be ignored for other assigned armed partitions.
Interior
• Acts as defined only after the last assigned partition is armed AWAY.
• In case that one of the partitions is disarmed or armed HOME, an alarm initiated from
this zone is ignored for all assigned partitions.
Interior follower
• Acts as defined only after the last assigned partition is armed AWAY.
• In case that one of the partitions is disarmed or armed HOME, an alarm initiated from
this zone is ignored for all assigned partitions.
• In case that one of the common area assigned partitions is in a delay state (and the
other partitions are armed), the alarm will behave as an interior follower for this
partition only. The event will be ignored for other assigned armed partitions.
Home / Delay
• Acts as a Perimeter-Follower type when all assigned partitions are armed AWAY.
• Acts as a Delay type when at least one of the assigned partitions is armed HOME.
• Will be ignored when at least one of the assigned partitions is disarmed.
Emergency
Fire
Flood
Gas
Temperature
24-hour silent
24-hour audible
Non-alarm
• Always armed.
