9 HOMEDEPOT.COM
Please contact 1-877-527-0313 for further assistance.
Installation (continued)
2a
Installing in Vertical Sliding Window
NOTE: The window installation kit can be used with vertical
sliding windows between 18 in. and 50 in. wide.
□ Cut the foam seal (LL) (adhesive type-long) and foam seal
(MM) (adhesive type-shorter) to the proper length, and
attach it to the window sash and frame.
□ Insert the vent panel assembly (HH), including extension
panels, if needed, into the window opening.
□ Extend the extension panels to the window width.
HH
II, JJ or KK
□ Cut the foam seal (AA) (non-adhesive type) to the window
width. Stuff the foam seal (AA) between the glass and the
window to prevent air and foreign objects from getting into
the room.
AA
□ Install the window lock bracket (GG) with screw (FF)
asshown, if needed.
GG
To Next Page
