Pre-operation (continued)
C
D
D
3
Installing Hinge
4
Installing The Door
□
□
Install the removed screw hole cover (1) onto the
screw hole in the upper right corner of the box (D).
Take out the upper left hinge (9) from the accessory
bag and install it to the upper left corner of the box
(D) with screws (3).
□
□
Remove the left lower hinge (10) from the accessory
pocket and install it onto the hinge retainer plate (11).
First install the top of the glass door (C) onto the upper
left hinge, then push the bottom to align it with the
lower left hinge (10), and nally x the screws (5)
1
9
3
8
10
11
5
NOTE:
After installation, please keep the
replaced upper right hinge (2) and lower
right hinge (4) properly for the convenience
of next use.
