Installation Guide & Owner’s Manual
TM
• If the system is mounted inside a cabinet, under a sink or on a sliding device, be careful that tubes are
not crushed or crimped� If the system is on a sliding device for easy access, make certain to create a coil
with the tubes that will allow the system to move in and out without causing damage or restriction�
• If the VistaPure system is to be installed remote to the autoclave(s) and/or in a cabinet, fish the solid
blue tubing behind cabinetry to the autoclave center� Join the solid blue tubing and the coiled blue
tubing with the white 1/4” x 3/8” push-type union that is already attached to one end of the coiled
tubing� Make certain to provide a restraint at the straight end of the coiled tubing near the union so that
when pulling out on the autoclave wand and coiled tubing the union connection is not stressed� Extra
lengths of tubing are included with each system� A mounting zip tie is provided with system�
RED From Cold Water Supply NATURAL To and From Tank BLUE STRAIGHT To Autoclave Area
BLACK To Drain WHITE To Faucet BLUE COILED To Autoclave Filler Wand
Attach colored tubing to the proper segments on the system manifold and the appliance/device as
shown below and on page 5� When attaching tubing to the push-type fittings, make certain all tubing
cuts are straight and free from burrs� Tubing must be firmly inserted into the fitting (11/16” plunge) to
avoid leaks�
5
6
Wand Installation
6A
6B
6C
USE: To use the wand, remove it from the clip holder, turn the blue valve handle so it’s inline with the
tubing, then press downward on the mushroom button� Water will flow from the spout�
STORAGE: To store the wand after use, turn the blue handle so it is 90º to the tubing and press the wand
into the clip holder�
Push wand assembly valve onto the end of the 3/8” O�D� coiled tubing� Firmly push and twist the
tubing to make certain it engages into the O-ring in the valve�
Attach the white 3/8” x 1/4” union adapter on the opposite end of the coiled tubing to the 1/4”
tubing that runs to the “Autoclave Wand” port on the VistaPure system manifold� Secure the
union adapter to a solid surface using the included mounting zip tie�
Attach the small wand holder clip to the desired location using the two screws provided� The
clip may be oriented in any direction and mounted in any location�
