vita Regency - Fastening Rafters & Caps

Fastening Rafters & Caps
13
12 x 12 Flat Top Pergola
1
Using 5/8” (16mm) self-auguring stainless steel screws attach
the pergola rafters to the rafter brackets.
Install decorative pergola end caps using vinyl weld.
Install the post caps using vinyl weld.
Final position your post trims.
1
2
3
STEP SEVEN
4
3
To position post trim in place:
1. Slide the post trim down.
2. Apply a generous amount of vinyl glue around the post
3. Slide the post trim back up to the desired location and
allow a few minutes for glue to cure.
4
2
To glue pergola end in place:
1. Apply a generous amount of vinyl glue to the pergola end as shown.
2. Slide the pergola end into the beam/rafter and allow a few minutes
for glue to cure.
