Vitilan i7 Pro - LCD Display Mode Switching; Mileage Display Mode Cycling; Speed Display Mode Switching



18
When power on, short-press to switch the mileage display mode, and the following
information is displayed cyclically: riding time (Time) → accumulated mileage (ODO) → power
information (Pow) → single mileage (Trip).
*If there is no key
operation for 5
seconds, the meter will
automatically return to
the single mileage
display state.
7.4 Speed Mode Switch
When power on, short press the to switch the speed display mode, and the following
information is displayed cyclically: real time speed (RT SPEED) → average speed (AVG SPEED) →
maximum speed (MAX SPEED).
PowerButton
ModeButton
