9
(16-2-10) FRZ：Image Freeze. Ex: FRZ►ON, means freeze
image, FRZ►OFF means unfreeze image.
(16-2-11) WB：White Balance Calibration. Ex: WB►SET means
calibrate white balance.
(16-3) Information○
f
: IN PCCAM or PLAYBLACK Mode, the shown
info are as following:
(16-3-1) SNAPSHOT: Take Picture.
(16-3-2) REC 00:00:00: Video Recording, each video
recording max 30mins.
(16-3-3) [12/30] IMG_000012: Picture Playback mode.
(16-3-4) [15/20] VID_000015: Video Playback mode.
(16-4) Function mode○
g
: Show the current operate mode.
(16-4-1) PC CAM: able to connect with PC software and
preview on HDMI monitor.
(16-4-2) USB DISK: Long press for 2 sec.,wait about 15
sec., Monitor will switch to show USB DISK. User can
directly read the SD card file on PC. Snapshot and
video recording function is disabled under this mode.
(16-4-3) PLAYBACK: Play the pictures and video. Snapshot
and video recording function is disabled under this
mode.
