2 Introduction
Note that the ball icon only is illuminated, indicating that the dedicated
congurationisselected.Thecolourofthebargraphandmarkerdetectionballisalso
set to the colour of the marker. If the line icon
is illuminated with the ball icon,
thisindicatesthattheDualcongurationisactivated(Dualmodeisdescribedlaterin
this document).
Either use the
pushbutton to select the marker type that is to be located. Or use
a long press on the
button to enter the user menu. Select the “Marker Type”
which will then cause the display to show the complete range of markers available
together with their operating frequencies. Use the “+” and “-” keys to scroll up and
down through the options. Press the
button to make your selection, then the
button to exit this screen.
Menu
About
Speaker volume
Sonde Configuration
Backlight
Frequency
Locate Perspective
Marker Type
Medium
Power (169.8kHz)
Water (145.7kHz)
Sanitary (121.6kHz)
Telephone (101.4kHz)
Gas (83kHz)
CATV (77kHz)
Non-Potable Water (66.35kHz)
Power Europe (134kHz)
Tip
Pressing and holding the
button will short cut you to the
frequency screen. Exit by pressing the
button.
Detecting a Marker in the Dedicated Mode
Switch on the locator and select the correct marker frequency.
Sweep the area of where the marker is to be located. Use a slow, deliberate arm
sweeping motion slowly moving forward making sure no area is missed.
Sweeping
action
Slowly walk forward
