Insert the battery into the middle of the frame and lock it with the battery key.
Make sure the battery switch is on to enhance your riding experience.
To remove the battery, insert the battery key and turn it to the "unlocked"
position before removing the battery.
First, install the battery bag on the handlebar, then pull out the power line connector
from under the battery bag, find the power line connector, and insert the power line
connector of the battery to complete the installation of the battery.
5.8 Installation of batteries
Applicable to models MT20 / MT20-P / FM201 / FM201-P / C26 / MT26G
5.9 Adjust the angle of brake rod, Meter, gear lever, accelerator and bell on
the handlebar, and tighten them with tools.
Congratulations! You have assembled the whole electric bike.
Applicable to models MT20 / MT20-P / FM201 / FM201-P / C26
Applicable to model MT26G
5.8.1
5.8.2
