Connect the seat and seat tube first. Insert the seat rod into rod receiver, and adjust
the position and height according to your riding habit. Tighten the seat with clamps.
Note: Please do not exceed the maximum saddle height. Do not lift the saddle to the
position above the safety line.
Take out the red reflector, install the reflector on the saddle tube, and tighten
the screws with the tool to complete the installation of the rear reflector.
Take out the red reflector, install the reflector on the rack, and tighten the screws
with the tool.
Connect the plug to the tail light cable and bind the cable to the rack with cable ties.
5.6 Installation of Saddle
5.7 Installation of reflector
Applicable to models MT20 / MT20-P / FM201 / FM201-P / C26 / MT26G
Applicable to models MT20 / FM201 / MT26G
Applicable to models MT20-P / FM201-P / C26
5.7.1
5.7.2
