Insert the threads of each pedal into the crank arm completely. Tighten the
pedal completely with the tool No.7 (M15 wrench).
Note: Rotate the pedal marked with “L” into the left crank anticlockwise. Rotate
the pedal marked with “R” into the right crank clockwise.
5.5 Installation of pedal
Applicable to models MT20 / MT20-P / FM201 / FM201-P / C26 / MT26G
